eDriveTC User Guide
13
Install Auxiliary Power Cable: -
1. Connect the Auxiliary
Power cable to the
eDriveTC console.
2. Twist the connector
firmly until it locks into
place.
Install CAN/Power Cable: -
1. Connect the CAN/
Power cable to the
eDriveTC console.
2. Twist the
connector firmly
until it locks into
place.
CAN/Power cable
