Table A-2: MGL-4 Combination Loop / GPS Antenna Specifications
Humidity 95% Non-Condensing
Operational Specifications
Item Specification
Frequency Range, Beacon 283.5 - 325 kHz
LNA Gain, Beacon 34 dB
Pre-Amplifier, Beacon Integral Low Noise Amplifier
Frequency Range, GPS 1.575 GHz (L1)
LNA Gain, GPS Various available
Power Specifications
Item Specification
Input Voltage 4.9-13 VDC supplied by receiver
Input Current 50-60 mA
Mechanical Characteristics
Item Specification
Enclosure PVC Plastic
Mounting Thread 1-14-UNS-2B
Length 128 mm (5.06”)
Width 128 mm (5.06”)
Height 84 mm (3.33”)
Weight 450 g (1.0 lb)
Antenna Connector TNC-S
Antenna Extension Cable RG-58U, < 15 m (45 ft) in Length
