MBX-4 User Guide
81
Table A-3: Internal Signal Splitter Specifications
Environmental Specifications
Item Specification
Storage Temperature -40×C to 80×C
Operating Temperature -30×C to 70×C
Humidity 100% Condensing
Item Specification
BCN Port - GPS Frequency Insertion Loss 35 dB nominal, >25 dB min.
BCN Port - Beacon Insertion Loss 0.2 dB nominal, 0.4 dB max.
GPS Port - GPS Frequency 3.5 dB nominal, <5 dB max.
GPS Port - Beacon Frequency 70 dB typical, 58 dB min.
