InstallatIon, servIce and troubleshootIng Procedures
GENERAL INFORMATION
This sections includes a general overview of the
information included in this manual and TIREMAAX
®
PRO and CP systems.
ABOUT THIS MANUAL
This manual is provided to support Hendrickson
TIREMAAX
®
CP and TIREMAAX
®
PRO tire inflation
systems. The manual provides the following
information:
• General Information
• Operation
• Components
• Installation
• Service
• Troubleshooting
• Glossary
• Appendices
SYSTEM OVERVIEW
The Hendrickson TIREMAAX tire inflation system
is available in two versions: TIREMAAX CP and
TIREMAAX PRO. System highlights include:
• TIREMAAX PRO and CP controllers use trailer air
tank supply to provide a constant regulated target
pressure to air seals and hoses to inflate all tires.
• TIREMAAX PRO additionally monitors and deflates
tire pressure as needed
FEATURES
Features include:
• Indicator lamp (Figure 4 on page 12) that
illuminates when regulated air flow exceeds the
designed threshold. This occurs while tires are
inflating or there is a system leak.
• Tire pressure is continuously and automatically
held at target pressure for inflation.
• Does not pressurize axle tube (helps prevent
contamination of seals).
• In-axle filter prevents hub contamination and
allows any wheel-end air leaks to evacuate
through the axle vent.
• Seal and line leaks will not pressurize wheel ends.
• No venting at wheel end helps prevent
contamination from entering hubcap.
• Integrated valves isolate tires from system when
there is a problem (e.g. damaged or flat tire).
• The rotary union is incorporated in the hubcap
assembly for simpler installation and service.
• Manual pressure check or fill is available through
tire hoses at the hubcap.
• Inflates tires and detects leaks.
• Air supply valve includes a screen that prevents
debris from entering system and helps keep lines
and seals clean.
• Tire target pressure set to OE specifications.
• TIREMAAX PRO includes a deflation pressure that
is preset greater than the target pressure. Excess
pressure above the deflation pressure is exhausted.
SYSTEM SPECIFICATIONS
Unless otherwise specified, specifications listed apply
to both TIREMAAX
®
PRO and CP.
SPECIFICATION US METRIC
CP tire pressure setting range 70 to 120 psi 482 to 827 kPa
PRO tire pressure setting
range
85 to 120 psi 586 to 827 kPa
Pressure check interval Continuous
Minimum operating voltage 9 volts
Indicator lamp current range 50 mA to 1 A
Inflate capacity (one tire in
approximately two minutes)
10 psi 69 kPa
Table 2: TIREMAAX
®
PRO
and
CP
general specifications
