User Manual – 5/14
3.2. Connecting and disconnecting the DJ Console
The DJ Console can be used in conjunction with an internal sound card (dedicated to network
gaming, for example) without causing conflicts on your computer. When you connect the DJ
Console it is automatically recognized as the main sound card, and once it is disconnected the
internal sound card resumes its original functions.
Consequently, you can connect and disconnect your DJ Console at any time, even when the
computer is switched on, thanks to its USB connection.
4. PRESENTATION
4.1. The cover
Your DJ Console has a cover, allowing you to transport it without any danger of damaging the top
face. This cover can also be attached to the underside of the DJ Console as an inclined base,
allowing you to use your DJ Console under optimal conditions. By default, the cover is configured
as an inclined base.
To detach the cover:
- Turn over the DJ Console and place it on a flat surface.
- Holding the DJ Console with one hand, take hold of the cover
by the OPEN opening.
- Pull the cover up towards you, pulling up on one side and
then the other in order to detach the cover.
To replace the cover:
- Position the tabs on the lower part of the cover in the
corresponding slots on the DJ Console.
- Apply pressure on both sides of the cover where the word
CLOSE appears until it snaps into place.
4.2. The shoulder strap
Your DJ Console also features a shoulder strap for easy transportation. To install the shoulder
strap:
- Thread the Velcro flaps through the two buckles on the
DJ Console.
- Attach the flaps to the Velcro band.

Hercules DJ CONSOLE Specifications

General

I/O ports	1 x audio - line-In; 1 x microphone - input; MIDI - input / output; 1 x audio - line-out - RCA; 1 x audio - line-out - mini-phone stereo 3.5 mm; 1 x headphones - output; Audio - SPDIF input; Audio - SPDIF output.
Audio quality	24 bit
Minimum RAM	64 MB
Minimum processor	Pentium II 400 MHz
Minimum storage drive space	100 MB
Compatible operating systems	Microsoft Windows 98 Second Edition / Windows ME, Microsoft Windows 2000 / XP
Audio system maximum sampling rate	48 kHz
Bundled software	Virtual DJ (DJ Console Edition) from Atomix Productions, a dedicated version of a professional DJ software suite; New DJ SE from GMIXON, the easy-to-use DJ mixing software; Ots CD Scratch 1200 and OtsDJ demo from Ots Labs, a virtual turntable CD player and a revolutionary MP3/CD/WAV playback system for DJs, radio stations and music lovers; Storm 2.0 DJ Edition from Storm Music Studio, a powerful audio sequencer; DJ Console Softmapper from Hercules, a powerful mapping interface allowing you to assign keyboard shortcuts to your DJ Console’s controls for hands-on control of audio applications (mapping of digital controls only).
Compatibility	Audio: Microsoft DirectSound compatible; ASIO 2.0 drivers included; General MIDI compatible.
