PARTS FUNCTION
Ignition switch
12
2
(1) Ignition switch
(2) Ignition key
(3) Steering lock position
3
1
“LOCK” position
“ON” ( )
position
“OFF”( )
position/
Lock open
Key cannot be removed
Engine cannot be started and no electrical
system will be functional.
Key can be removed
Key can be removed
Key removal
Steering can be locked.
FunctionKey position
“LOCK”
“ON” ( )
“OFF”( )
The LCD panel illuminates & initial display of
multi function digital segments are displayed.
The tachometer segment and the fuel gauge
segment will swing to the maximum scale once
and back to its normal position. The engine can
be started. Turn signal lamp, horn, tail/stop
lamp, fuel gauge, pass lamp, position lamps &
neutral indicator will be functional. Programmed
FI malfunction indicator lamp (MIL) illuminates
continuously and i3s indicator glows for 2
seconds.
