31
If your vehicle doesn't operate as described in
above flow diagram, please visit your
Authorised Hero MotoCorp workshop.
WARNING
!!
Regularly inspect the functionality of "Side
stand engine kill” feature and in case of any
malfunction visit Authorised Hero MotoCorp
workshop.
FUEL TANK
Fuel tank capacity is 10 litres (Minimum fuel
to be maintained above one segment blinking
of fuel level indicator).
• To remove the fuel tank cap (1), open the
key hole cover (2) and insert the ignition
key (3) turn it clockwise and remove the
cap.
(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
1
2
(4) Fuel (5) Filler neck
4
5
CAUTION
!!
Do not park the vehicle under direct sunlight
as it causes evaporation of petrol due to heat
and deterioration of paint gloss due to ultra
violet rays.
WARNING
!!
Petrol is extremely flammable and is explosive
under certain conditions. Refill in a well
ventilated area with the engine stopped. Do
not smoke or allow flames or sparks in the
area where the vehicle is refilled or where
petrol is stored.
•
Do not overfill the tank. There should be no
fuel (4) in the filler neck (5).
•
For locking, position the cap with “ ” ▲
mark facing towards the front, back on the
opening and press gently. The key springs
back to the normal position and the cap
gets locked.
3
