45
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
UPPER
LOWER
1
(4) Engine oil check bolt
•
After checking the oil circulation, tighten the
engine oil check bolt.
•
Stop the engine and wait for 2-3 minutes.
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
•
Remove the oil level dipstick and check the
oil level.
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
ENGINE OIL
Use hero genuine engine oil or recommended
grade oil.
BRAND: Hero 4T plus
GRADE: SAE 10W 30 SL Grade
(JASO MA2).
Manufactured by:
•
Tide Water Oil Co. (India) Ltd.
•
Savita Oil Technologies Limited.
•
Bharat Petroleum Corporation Limited.
OIL CAPACITY: 0.95 litre (disassembly)
: 0.75 litre (at oil change)
Engine oil level inspection/Top up
process
Check engine oil level each day before
operating the vehicle. The oil level dipstick (1)
is on the right crankcase cover for measuring
oil level. Oil level must be maintained between
the upper (2) and lower (3) level marks on
the oil level dipstick.
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
•
Park the vehicle on its main stand.
•
Turn the i3s switch to “OFF” position.
•
Start the engine & let it idle for 3-5
minutes.
•
Slightly loosen the engine oil check bolt (4)
and check the engine oil entry into the
cylinder head.
3
2
4
