69
•
Ensure the battery leads are properly
connected to the battery terminals during
installation.
Battery removal
•
FF” ( ). Make sure the ignition switch is “O
•
(pages 32)Remove the seat .
•
Remove the left side cover screws (1) and
remove the side cover (2) by releasing the
tabs from the slots (3) and lugs from the
grommets (4).
2
(1) Left side cover screws (2) Side cover
(3) Tab/slot (4) Lugs/grommets
• Remove the battery clamp bolt (5) and the
battery clamp (6).
• Disconnect the negative (-)ve terminal lead
(7) from the battery first, then disconnect
the positive (+)ve terminal lead (8).
• (9) Pullout the battery from the battery box.
(5) Battery clamp bolt (6) Battery clamp
(7) (-)ve terminal (8) (+)ve terminal
(9) Battery
9
8
Battery installation
•
Reinstall in the reverse order of removal. Be
sure to connect the positive (+) terminal ve
first, then the negative (-) terminal.ve
•
Check all fasteners are secured properly.
FUSE REPLACEMENT
Fuse box : air (1) Location: Mounted on the
cleaner assembly 2 ( ) left hand side.
Fuse ype: t Blade fuse
Circuit fuse ( ) : 15A, 10A, 10A, 10A 3
Spare fuse ( ) : 15A, 10A 4
6
1
34
7
5
