29
• The i3s system will not function if rider puts
the i3s switch to”OFF” position.
• If the battery voltage is low and engine r/min
is less than 2000, there will be 3 continuos
blinks after every 6 secs.
• If the low battery voltage is detected while
the ignition key is in “ON” position or engine
is in running condition, the i3s function will
be deactivated or may not function properly
until the rider turns the ignition switch to
"OFF" ( ) position and then back to "ON"
( ) position.
• If the vehicle is driven without battery or with
the dead battery and the engine r/min is less
than 2000 . The i3s indicator on the
speedometer will continuouslyblink at every
1.5 secs.
• i3s function If the vehicle has fallen down,
may not work properly. B efore restarting the
engine you must turn the ignition switch to
"OFF" position and then back to "ON" ( )
( ) position.
• If the battery is in healthy condition and the
i3s system does not work properly, it is
recommended to visit your Authorised Hero
MotoCorp workshop.
• i3s system will not function properly if the
vehicle battery is low/dead or driven without
battery.
• If vehicle diagnoses with any problem in
electronic control unit (ECU) the i3s function
will not work.
NOTE
SIDE STAND INDICATOR/SWITCH
For the safety of the customer a side stand
indicator (1) is provided.
(1) Side stand indicator
A side stand switch (2) is provided in the side
stand, when the side stand is down (ignition
switch “ON” ( )), the switch enables the side
stand indicator lamp to glow on the
speedometer panel.
(2) Side stand switch (3) Side stand spring
2
1
3
