Sl. No. Description Function
Instruments and Indicators
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
1 2
6 5
4
3
(1)
Speedometer
Indicates driving speed.
(2)
Odometer
Shows accumulated mileage.
(3)
Gear shifting
Maximum operating speed in each gear.
(4)
Turn signal indicators Flashes when turn signal switch is operated.
(5)
High beam indicator
Light glows when headlamp is in “Hi” Beam.
(6)
Neutral Indicator
Light glows when vehicle is in neutral.
13
