Ÿ For locking, position the cap with “▲”
mark facing towards the front, back on the
opening and press gently. The key springs
back to the normal position and cap gets
locked.
3
22
1
(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
(4) Filler Neck (5) Fuel
5
4
“OFF” ( ) Position
At “OFF” position (1) , fuel cannot flow from
the tank to the carburetor. Turn the valve
“OFF” whenever the vehicle is not in use.
The three way fuel valve is on the left side near
the carburetor.
Fuel valve
CAUTION
!!
Do not park the vehicle under direct sunlight
as it causes evaporation of petrol due to heat
and deterioration of paint gloss due to ultra
violet rays.
WARNING
!!
Petrol is extremely flammable and is explosive
under certain conditions. Refill in a well
ventilated area with the engine stopped. Do not
smoke or allow flames or sparks in the area
where the vehicle is refilled or where petrol is
stored.
(1) “OFF” ( ) position
1
15
