HERO HF-DAWN - Vehicle Views

(1) Horn switch
(2) Turn signal lamp switch
(3) Clutch lever
(4) Rear view mirror
(5) Headlamp dimmer switch
(7) Speedometer
(6) Odometer
(11) Front brake lever
(15) Leg guard (Optional)
(13) Ignition switch
(8) Turn signal indicator
(14) Fuel tank cap
(10) High beam indicator
(9) Neutral indicator
(12) Throttle grip
