HERO HF-DAWN - Page 6

(7) Side stand
(8) Left side cover
(9) Pillion foot rest
(10) Women pillion step
(Optional)
(11) Saree guard
(13) Reflex reflector
(14) Tail/Stop lamp
(12) Rear turn signal lamp (1) Fuel valve
(3) Gear shift pedal
(4) Rider foot rest
(6) Main stand
(5) Side stand switch
(2) Carburetor
VEHICLE VIEWS
14
13
12
11
10
9
8
7
6
5
4
3
2
1
*Accessories and features shown may not be part of standard fitment.
LEFT SIDE VIEW
3
