Now blow the dust from the surface of the
paper element about 50 mm away from it,
O
with the air nozzle (11) at an angle of 45
•
Replace it earlier if it becomes very dirty,
damaged on surface or on the sealing area.
•
Install the air cleaner element on holder,
insert the air cleaner assembly into the inlet
air duct & press gently to fix the mounting
clamp in housing. Ensure cover lug should
take proper seat on the other side of the
mounting clamp.
and moving it along the paper pleats.
(9) Air cleaner element (10) Element holder
(11) Air nozzle
9
1110
O
45
50 mm
CAUTION
!!
•
Never wash the air cleaner element. Only blow
air for cleaning the dust, as explained. Replace
air cleaner element every 12000 km.
•
Never blow air initially from outside to inside
as the fine dust particles may go deep inside
the element.
(b) Air cleaner drain tube cleaning
Drain the deposit into a suitable container by
pressing the drain tube end. Follow the above
process more frequently when riding in rain or
at full throttle.
(1) Drain tube
1
31
•
Start cleaning by directing the air nozzle (11)
inside the element and cleaning it by rotating
the element about its axis.
•
Remove the air cleaner element (9) from
the element holder (10).
•
The air cleaner element should be cleaned
by blowing moisture free pressurized air.
•
Air cleaner element cleaning
