(a) Fuel gauge
The fuel gauge (1) is of a Liquid Crystal
Display (LCD) type. The approximate
amount of fuel quantity available in the fuel
tank is indicated by the number of segments
(2) in the display. If all the segments (2) are
displayed it means fuel quantity in the fuel tank
is litres (Minimum). 1 1
The Odometer (3) shows accumulated
distance travelled.
If only one segment (2) is displayed and
blinks, this indicates that the fuel quantity is
low and is in reserve. The fuel tank should be
refilled as soon as possible.
The Tripmeter (4) shows distance travelled
per trip. The Tripmeter can be reset to zero by
pressing the RESET button (5).
(b) Odometer/Tripmeter/Service
reminder indicator
The Service Reminder Indicator (6) is to
indicate user to bring the vehicle to an
(1) Fuel gauge (2) Segments
14
(3) Odometer (4) Tripmeter
(5) Reset button (6) Service reminder indicator
Authorised Distributor/Dealer for service. The
indicator shall start blinking when the vehicle
covers kilometers as specified in the
maintenance schedule. The indicator will keep
on blinking throughout the kilometer interval
for a particular service and will stay ‘‘ON’’
thereafter. The Service Reminder Indicator
can only be reset at an Authorised Distributor/
Dealer.
the handle bar towards left or right & push the
key downwards & turn towards “LOCK”
position. After locking, take out the key.
Steering lock
Steering lock is with ignition switch, put the
ignition key (1) to “OFF” position & turn
2
1
FEATURES
4
3
6
5
