HERO IGNITOR TECHNO - Suspension; Suspension Inspection and Adjustment

43
Rear brake wear indication
Front brake wear indication
3
1
4
(1) Arrow (2) Brake arm
(3) Reference mark (4) Brake Panel
2
2
4
Front Rear
(1) Arrow (2) Brake arm
(3) Reference mark (4) Brake Panel
Rear shock absorber adjustment can be made
according to the load/road conditions.
•
Check the rear shock absorber by pushing
hard downwards on rear grip while the
vehicle is not parked on stand. The
suspension action should be smooth and
their should be no oil leakage.
(b) Rear shock absorber adjustment
•
In direction A: Stiffer
•
In direction B: Softer
(1) Pin spanner
B
A
1
Suspension
(a) Front and rear suspension inspection
•
Check the front forks by locking the
front brake and pumping the front fork up
and down vigorously. The suspension action
should be smooth and there should be no oil
leakage.
1
3
