(2) Horn switch
(5) Rear view mirror
(7) Side stand indicator
(10) Fuel gauge
(9) Speedometer
(6) Dimmer switch/Passing switch
(11) Service reminder
(3) Turn signal switch
(4) Integrated brake lever
(8) Hi beam indicator
(1) Turn signal indicator
(20) MIL indicator
(18) Ignition switch with steering lock, seat
lock and fuel lid opener
(19) Mode button
(12) Tripmeter
(13) Master cylinder (inside)
(14) Front brake lever
(15) Throttle grip
(16) Starter switch
(17) Odometer
TOP VIEW
VEHICLE VIEWS
10
7
8
11 9
6
1
2
3
4
5
12
13
18
14
15
16
17
20
19
