HERO MAESTRO EDGE 125 PROGRAMMED FI - BODY PARTS REMOVAL; Center Compartment Removal

32
(a) Center compartment
•
Remove the bolts (1) from the center
compartment.
Removal
•
Open the seat (page 26).
BODY PARTS REMOVAL
(1) Bolts
(3) USB charger connector
(2) Boot lamp connector
(4) Center compartment
4 3
2
1
lamp connector (2) and USB charger
connector (3).
•
Remove the center compartment (4).
•
Slightly lift up the center compartment
from the rear and disconnect the boot
Move the women pillion step to open. Folding
can be done by moving the women pillion step
in reverse direction.
