33
(2) Bolts
2
•
Remove the center cover (4).
•
Remove the screws (3) from the center
cover.
•
Remove the screws (5).
(3) Screws (4) Center cover
4
3
•
Remove the rear grip bolts(2).
(1) Bolt
1
•
Remove the center compartment (page 27).
Removal
•
Remove the tray fuel sub assembly bolt (1).
(b) Body cover
Installation is in the reverse order of removal.
Installation
Park the vehicle on its main stand when
servicing the vehicle with the center
compartment removed.
NOTE
