30
(2) Rear luggage hook
The front inner box (1) is provided on the
inner cover to carry some valuable items,
documents, etc.
(j) Front inner box (Optional)
(1) Front inner box
1
Never exceed the maximum weight limit of the
front inner box otherwise handling and
stability may be severely affected.
MAXIMUM WEIGHT LIMIT: 1.5 Kg
(k) Side stand/indicator/switch
(Optional)
For the safety of the customer a side stand
indicator (1) is provided.
2
(1) Side stand indicator
1
A side stand switch (2) is provided in the side
stand, when the side stand is down (Ignition
switch “ON”), the switch enables the side
stand indicator lamp to glow on the
speedometer panel.
(2) Side stand switch (3) Side stand spring
3
2
