56
(1) Air cleaner cover screws
1
(2) Air cleaner cover
AIR CLEANER ELEMENT
• Remove the air cleaner cover screws (1).
Refer to the safety precautions (page 54).
• Remove the body cover (page 35).
The air cleaner element is of viscous type, it
should be replaced at regular intervals
(pages 55). Early replacement may be
required when riding in unusually wet or dusty
areas.
•
Remove the air cleaner cover (2).
•
Remove the air cleaner assembly (3) from
housing (4).
2
(3) Air cleaner assembly
(4) Air cleaner housing
3
4
