“ ” downwards for low beam “ ” .
Press the switch to “PASS” position to
operate the passing lamp.
3. Horn switch ( )
Shift the turn signal switch sideways for
right/left indications and leave it to come back
to its normal position on its own.
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
inside as directed on the switch.
Left handlebar controls
1. Dimmer switch/Passing switch
Press the switch upwards for high beam
2. Turn signal switch ( )
HANDLEBAR SWITCHES CONTROLS
Press the switch to operate the horn.
25
The starter switch (1) is next to the throttle
grip.
1. Starter switch ( )
When the starter switch is pressed, the starter
motor cranks the engine. See (page 42) for
the starting procedure.
Right handlebar controls
(1) Dimmer switch/Passing switch
(2) Turn signal switch
(3) Horn switch
1
3
2
(1) Starter switch
1
FEATURES
(a) Steering lock
(1) Ignition switch (A) Push in (B) Turn to lock
1
A
B
