35
(9) Fuel tank lid lock cable
•
Remove the fuel filler cap (page 19).
•
Disconnect the tail/stop lamp connector
(10).
(10) Tail/stop lamp connector
10
•
Pull the body cover slightly backwards and
release the tabs (11) from it slots (12)
from both sides of the vehicle.
11
(11) Tabs (12) Slots
12
•
Disconnect the drain tube from the joint
(13).
• Release the body cover from its frame.
9
