NOTE
•
Running the engine with insufficient oil may
cause engine damage.
•
Top up if required after every 3000 km.
Engine oil replacement/
Change the engine oil with the engine at
normal operating temperature and the vehicle
on its main stand to assure complete and rapid
draining.
•
Remove the oil level dipstick.
•
Place an oil drain pan under the crankcase
and remove the oil drain bolt (1) with
sealing washer.
Oil strainer cleaning
(1) Drain bolt
1
•
Remove the oil strainer screen cap (2).
•
The spring (3) and oil strainer screen (4)
will come out when the oil strainer screen
cap is removed.
•
Clean the oil strainer screen.
•
Check that the oil strainer screen, sealing
rubber and cap O-ring (5) are in good
condition.
(2) Oil strainer screen cap
2
44
33
55
(3) Spring (4) Oil strainer screen (5) O-ring
• Install the oil strainer screen, spring and oil
strainer screen cap. Install the drain plug.
60
