Herz firestar Lambda 18 - Page 12

5
Boiler operation
12 Betriebsanleitung_firestar_18-40_Lambda_Englisch_V1.6
Legend:
1… Control NanoControl
8 … Viewing glass
15 … Ventilator
2 … Filling shaft door
9 … Ash tray
16 … Heat exchanger pipes
3 … Primary air feed
10 … Secondary air aperture
17 … Cleaning brush
4 … Lighting-up door
11 … Primary air aperture
18 … Bellows for burner plate
5 … Burner plate
12 … Cleaning cover
19 … Bellows for primary air feeds
6 … Secondary air aperture
13 … Turbulators
7 … Ash doors
14 … Lambda sensor
18
10
11
12
14
15
13
16
6
9
7
8
5
4
3
2
1
17
19
