Herz firestar Lambda 18 - Aggregate-Test Input (E)

Description of the menu navigation and adjustment values
9
Betriebsanleitung_firestar_18-40_Lambda_Englisch_V1.6 25
9.5 Aggregate-Test Input (E)
DESCRIPTION
E01
STL (password protected)
Input Safety temperature limiter (STL) Switch-off
E02
DOOR SWITCH (password protected)
Input door switch
E03
ROTARY SPEED (password protected)
Input of suction speed in %
E04
O2 (password protected)
Input of actual O2 values in %
E05
HEC MONITORING (password protected)
Input Heat exchanger cleaning - monitoring
By pressing the button:
„On/Off“:
The equipment is switched on/off
„F1“:
(S) changes into menu „STATUS“ and deactivates AGGREGATE-TEST
„F2“:
The bar is pushed up
„F3“:
The bar is pushed down
„F4“:
(A) changes into menu „AGGREGATE-TEST OUTPUT“
F1
F2
F3
F4
FS 20
1
E01
E02
E03
E04
E05
0
X
100
9.0
X
%
O2%
S
A
