Description of the menu navigation and adjustment values
24 Betriebsanleitung_firestar_18-40_Lambda_Englisch_V1.6
9.4 Aggregate-Test Output (A)
Only available when Code is active and the boiler condition is UNIT OFF(1)!
DESCRIPTION
A01
BF-PUMP (password protected):
Output Backflow-pump
A02
BF-MIXER OPEN (password protected):
Output Backflow-mixer
A03
BF-MIXER CLOSED (password protected):
Output Backflow-mixer
A04
ID FAN (password protected):
Output ID-Fan in %
A05
LAMBDA HEATING (password protected):
Output Lambda heating
A06
PRIMARY AIR FLAP (password protected):
Output Primary air flap position in %
A07
SECONDARY AIR FLAP (password protected):
Output Secondary air flap position in %
A08
HEAT EXCHANGER CLEANING (HEC) (password protected):
Output Heat exchanger cleaning
A09
COMPOSITE ERROR / ALARM (password protected):
Output Composite error / Alarm
By pressing the button:
„On/Off“:
The equipment is switched on/off
„F1“:
(E) changes into menu „AGGREGATE-TEST INPUT“
„F2“:
The bar is pushed up
„F3“:
The bar is pushed down
„F4“:
The value can be modified
F1
F2
F3
F4
FS 20
1
E
A01
A02
A03
A04
A05
X
0
0
X
X
%
