Hesai PandarQT User Manual

4
1.4 Specifications
SENSOR
MECHANICAL/ELECTRICAL/OPERATIONAL
Scanning Method
Mechanical Rotation
Laser Class
Class 1 Eye Safe
Channel
64
Ingress Protection
IP67
Range
0.1 to 30 m (at 20% reflectivity)
Dimensions
Height: 75.0 mm
Range Accuracy
±2 cm (Typical)
Diameter: 80.2 mm
FOV (Horizontal)
360°
Operating Voltage
DC 9 to 55 V
Resolution (Horizontal)
0.6° (with 0.15° gap)
Power Consumption
8 W
FOV (Vertical)
104.2° (-52.1° to +52.1°)
Operating Temperature
-20℃ to 65℃
Resolution (Vertical)
Finest at 1.5° (with min. gap 0.3°)
Weight
0.4 kg
Frame Rate
10 Hz
DATA I/O
Returns
Single Return (First)
Data Transmission
UDP/IP Ethernet (Automotive 100BASE-T1)
Dual Return (First & Second)
Slave Mode
Data Outputs
Distance, Azimuth Angle
CERTIFICATIONS
Background Illumination
RoHS, REACH, WEEE
Data Points Generated
Single Return Mode: 384,000 pts/s
CE, FCC, FDA, IC
Dual Return Mode: 768,000 pts/s
Clock Source
PTP / GPS
PTP Clock Accuracy
≤1 μs
PTP Clock Drift
≤1 μs/s
NOTE Specifications are subject to change without notice.
NOTE Range accuracy as the average range error across all channels may vary with range, temperature and target reflectivity.
NOTE 4-pin connectors only support PTP as the clock source.
NOTE Output of background Illumination data is not yet supported.
