Moving the Machine Axes
The machine axes are to be moved by running a part program or using the joystick of the NJB terminal.
Caution
Avoid moving the machine axes by pushing on their moving parts.
Caution
Run the AUTOZERO procedure to restore correct Jogbox operation if the NJB
terminal is knocked or dropped or if axis position holding instability is found
after pressing the ‘’enable’’ button.
NJB Jogbox AUTOZERO procedure
AUTOZERO is not a procedure for ordinary use but must only be carried out if axis position holding instability
is found.
Press the four Jogbox keys at the same time to start the AUTOZERO procedure Figure 13.
Figure 13 Starting the AUTOZERO procedure
