Air Supply System
This section contains the instructions for the preventive maintenance of the air supply system of the
measuring machine.
Figure 37 Pneumatic central unit
1. Pressure regulator
2. Air pressure gauge
3. Secondary filter
4. Primary filter
5. On-off valve
6. Air inlet
A
A
1 2 3 4 65
