52
•
GLOBAL S - User Manual
Operator Workstation Dimensions
Figure 21 Overall Dimensions of the Operator Workstation
Operator Workstation weight
113 kg (250 lb)
Desk Extension weight
32 kg (70 lb)
Max. workstation load limit
890N (90kgf, 200 lb)
