HEXING HXE310 - Relay Control Command

User manual for poly-phase meter
21
is not allowed except that via system or PC
software sending cancel relay off command
1
Connected(1)
In this status, relay is on
2
Ready for
connected(2)
In this status, relay is off
10.2 Relay control command
Transform
No.
Transfer Name
Transform explain
a
Remote_reconnect
Remote reconnect, From Disconnected(0) to
Connected(1), no need manual control
b
Remote_disconnect
Remote disconnect, From Connected(1) to
Disconnected(0)
c
Remote_disconnect
Remote disconnect, From Ready for
connected(2) to Disconnected(0)
d
Remote_reconnect
Remote reconnect, From Disconnected(0)to
Ready for connected(2)
From Ready for connected(2) to
Connected(1) need local or manual
command
e
Manual_reconnect
Manual reconnect, From Ready for
connected(2) to connected(1)
f
Manual_disconnect
Manual disconnect, From Connected(1) to
Ready for connected(2)
From Ready for connected(2) to
Connected(1) need local or manual
command
g
Local_disconnect
Local disconnect, From Connected(1) to
Ready for connected(2)
From Ready for connected(2) to
Connected(1) need local or manual
command
h
Local_reconnect
Local reconnect, From Ready for
connected(2) to Connected(1)
