25 Parameters
Electrical
Reference Voltage
3P4W: 3×220/380V, 3×230/400V, 3×240/415V
Basic current
5A
Maximum current
80A,100A
Starting current
≤0.4%Ib(active) ≤0.5%Ib(reactive)
Frequency
50Hz±2%
Consumption in
current circuit
≤2VA
Consumption in
voltage circuit
≤2W/10VA without communication
≤5W/25VA with communication
Battery life
15years
Data retention
>15years
Meter life
15years
Impulse constant
1000imp/kWh, 2000imp/kWh
1000imp/kvarh, 2000imp/kvarh
External influence
Protection
IP54(indoor)
Material for meter case
compliance
ISO 75
Operating temperature
-40℃~+70℃
Storage temperature
-40℃~+70℃
Relative humidity
≤95%
Atmospheric pressure
63kPa-106kPa
Electromagnetic compliance
Fast transient burst
4kV
Surge voltage
4kV
Electrical insulation
impulse voltage
6kV
AC voltage
4kV
Accuracy
Class (IEC) active
Class (EN) active
Class (IEC) reactive
1
B
2
Standard Compliance
IEC62052-11,
IEC62053-21,
IEC62053-23,
