Hi-Link HLK-RM04 - Web Configuration

Hi-Link (HK)Co.,Ltd sky:hlktech
Http://www.hlktech.net Tel:0755-23152658-821
15
Chart 13.UDP Client
In this mode, the module directly sends the serial data to the specified ip, port. The serial data
returned from the server-side will be distributed to serial port.
4.7 Parameter configuration direction
The module provides two ways for the configuration parameters：
1.Web page；
2. Serial AT command.
Access to WEB configuration page requires the confirmation of the module’s IP addresses, as
well as the user name and password that authenticated by WEB.
Configurating parameters through the serial port AT command needs to make the module into
the AT command mode first.
Serial configuration tool HLK-RM04_CONFIG ： Configurate the module through AT
command，provide a easier and convenient configuration process through the configuration
combination of each parameter.
5 WEB configuration
HLK-RM04
UDP Client
UDP Server
