Through the appropriate settings, the data between COM1 and WIFI network can achieve mutual
conversion.
WIFI safety: support all encryption methods at present.
In this mode, WIFI device can connect with the module and become the device under WIFI
LAN.
4.4 Default mode
Chart 6.Default mode model
In this mode, WIFI enable, module works in the AP mode, ETH1, ETH2 function enable.
ETH1 works as WAN, ETH2 works as LAN. Through the appropriate settings, the data between
COM1 and network can achieve mutual conversion.
WIFI safety: support all encryption methods at present.
In this mode, WIFI device can connect with the module and become the device under WIFI
LAN.
WAN default IP is dynamic IP address. LAN, WIFI for the same local area network, enabled by
default DHCP server.
4.5 Serial work mode switching
Module serial work status is defined as two modes: transparent transmission mode, the AT
command mode
DHCP ENABLE
SERIAL
HLK-RM04 MCU
WIFI CLIENT
(PHONE、pad)
