Functional Parameters
WIFI work mode Client/AP/Router
WDS Function Support WDS wireless bridge connection
Wireless MAC address filtering
Wireless security function switch
64/128/152 bit WEP encryption
Wireless security
WPA-PSK/WPA2-PSK、WPA/WPA2 security mechanism
Remote Web management
Configuration file import and export
Network management
WEB software upgrade
Serial to Ethernet
Maximum transmission
rate
230400bps
TCP connection Max connection number>20
UDP connection Max connection number>20
Serial baud rate 50~230400bps
Other Parameters
Status indicator Status indicator
Operating temperature：-20-70℃
Operating humidity：10%-90%RH（noncondensing）
Storage temperature：-40-80℃
Environmental standard
Storage humidity：5%-90%RH（noncondensing）
Additional properties Frequency bandwidth optional：20MHz、40MHz，Automatic
2.2 Hardware Explanation
2.2.1 Mechanical Dimensions
HLK-RM04 Mechanical Dimensions is shown in the following picture：
