Hi-Link HLK-RM04 User Manual

Hi-Link (HK)Co.,Ltd sky:hlktech
Http://www.hlktech.net Tel:0755-23152658-821
48
Tes
100ms
Trst
6s
10 Firmware upgrade
1. Restore the factory value.
2. Pc can connect with module through Ethernet, ip: 192.168.16.123/255.255.255.0. Browser
visits 192.168.16.254. Username / password: admin / admin.
3. Open the following page. Select the appropriate firmware, click apply upgrades. Wait about
3 minutes. Can not cut out the upgrade process, otherwise it may cause damage to the module.
Appendix A document revision record
Version
number
Revision range Date
1.00 Draft version 2012-9-10
1.10
2012-12-1
1.20
Firmware v1.41
2013-01-14
1.3
Add serial 2 function
2013-11-13
