General Operations
Satellite led
(green)
Always on More than 4 satellites tracked successfully
Slow flash Loss satellite s and try re-tracking
Off
1. mother board error resulting in no data output
while resetting receiver
2. mother board error resulting in no data output
while in static mode
Led displaying in different mode:
1. Work Mode (double click F1 to enter work mode setting, then
single click F1 to choose work modes among static, rover and base.
After that sin gle click power button to confirm the current setting.
If no confirming within 10 seconds, the receiver will autom atically
confirm the current settings.）:
● on ○ off
Mode
Satellite led Status led
(green led） (green led of the dual-color led）
Base
● ○
Rover
○ ●
Static
● ●
2. Data Link (double click F2 to enter data link setting, then single
click F2 to choose After that single click power button to confirm the
current setting. If
22
