VertX V1000 (CS) Quick Installation Guide
Example: Input 1, V1000 is: P14 Pin1 is + and Pin 2 is -.
Supervised inputs can be configured for:
Except for door monitor, all other
inputs default to NO, unsupervised:
Input
V2000 V1000 V100 V200 V300
number
P2 Pins 1/2 P2 Pins 1/2
1 P14 Pins 1/2 P1 Pins 1/2 P6 Pins 2/1
Door Monitor Door Monitor
P2 Pins 3/4 P2 Pins 3/4
2 P11 Pins 4/3 P1 Pins 3/4 P3 Pins 1/2
REX Input REX Input
P5 Pins 4/3 P7 Pins 8/7 P5 Pins 4/3 P7 Pins 8/7
3 P1 Pins 5/6
Door Monitor Tamper Door Monitor Tamper
P5 Pins 2/1 P7 Pins 6/5 P5 Pins 2/1 P7 Pins 6/5
4 P1 Pins 7/8
REX Input AC Fail REX Input AC Fail
P7 Pins 8/7 P7 Pins 4/3 P7 Pins 8/7 P1 Pins 9/10 P7 Pins 4/3
5
Tamper Batt Fail Tamper Batt Fail
P7 Pins 6/5 P7 Pins 6/5 P2 Pins 1/2
6
AC Fail AC Fail
P7 Pins 4/3 P7 Pins 4/3 P2 Pins 3/4
7
Batt Fail Batt Fail
8 P2 Pins 5/6
9 P4 Pins 10/9
10 P4 Pins 8/7
11 P4 Pins 6/5
12 P4 Pins 4/3
13 P4 Pins 2/1
14 P5 Pins 6/5
15 P5 Pins 4/3
16 P5 Pins 2/1
17
P7 Pins 8/7
Tamper
18
P7 Pins 6/5
AC Fail
19
P7 Pins 4/3
Batt Fail
