User Manual of the DS-1004K keyboard
19
Steps:
1. Press numeric button 1 and press MON.
2. Press numeric button 2 and press CAM-G button.
3.
Press HOLD button.
4.
Press RUN button.
5.
Press LAST button.

To set the preset, turn the key to the PROGRAM mode, press the numeric button and press CAM button to choose camera.
Press numeric button and press preset button the set preset.

To call the preset, switch to the OPERATE mode and press the numeric button and press CAM button to choose the
camera.
Press the numeric button and press preset button to call the preset.
Setting the patrol:
Steps:
1.
Turn the key to PROGRAM mode, press the numeric and press CAM button to choose camera.
2.
Press the numeric button and press patrol button to choose patrol to set.
3.
Press the numeric button and ENTER button to call the preset you want to add to the patrol.
4.
Press the numeric button and the ENTER button to set the interval for patrol.
5.
Press the numeric button and ENTER button to set patrol speed.
6.
Press patrol button again to finish your setting.
Calling the patrol:
Steps:
1.
Turn the key to the OPERATE mode, press the numeric button and press CAM button to choose camera.
2.
Press the numeric button and press patrol button to call the patrol.
Setting the pattern,
Steps:
1.
Switch to the PROGRAM mode, and press the numeric button and press the CAM button to choose camera.
2.
Press the numeric button and press the pattern button
3. Use the joystick to control the PTZ to record the PTZ movement.
4.
Press the pattern button again to set the pattern.
5.
To call the pattern, switch to the OPERATE mode, press the numeric button and press CAM button to choose
camera.
6. Press the numeric button and press pattern to call the pattern.

HIKVISION DS-1004KI Specifications

General

Numeric keypad	Yes
Keyboard layout	-
Pointing device	Trackball
Device interface	RS-485
Connectivity technology	Wired
Wrist rest	No
Product color	Black
Keyboard style	Straight
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Control panel
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	163 mm
Width	434 mm
Height	43 mm
Keyboard weight	1250 g
Keyboard dimensions (WxDxH)	434 x 163 x 43 mm
