User Manual of the DS-1004K keyboard
20
3.4 Controlling the Analog Matrix by Keyboard
Setting the Keyboard Parameters to Control Analog Matrix
The RS-232 communication is used when the DS-1004KI keyboard is controlling the analog matrix system. And the following
parameters must be correctly configured for the RS-232 port: protocol, baud rate, data bit, stop bit and parity. ZT-1.0, ZT-2.0,
EXTRON and CREATOR protocols are supported by the keyboard.
Turn the key to MENU; press the SITE button to select the address for analog matrix to be configured; and set the RS-232 parameters.
To set the RS-232 parameters:
Steps:
1. Move the joystick left/right to view selections.
2. Move the joystick up/down to select a parameter.
3. Move the joystick up/down to select YES in the COPYALL selection if you want to copy the settings to all the other devices.
The default setting is NO.
4. Turn the key to Operate to operate the device remotely.
Analog Matrix Controlling Operation
Main Operation
：

Use the SITE button to choose the analog matrix by its address.
 To display the video from a camera to a certain monitor.
In the OPERATE mode, press the numeric button and the press the MON button to choose the video output monitor.
Press the numeric button and press CAM button.

Use the NEXT button and the LAST button to realize the switch of the video input.

Use CLEAR button to delete the number you input or exit the operation.

HIKVISION DS-1004KI Specifications

General

Numeric keypad	Yes
Keyboard layout	-
Pointing device	Trackball
Device interface	RS-485
Connectivity technology	Wired
Wrist rest	No
Product color	Black
Keyboard style	Straight
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Control panel
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	163 mm
Width	434 mm
Height	43 mm
Keyboard weight	1250 g
Keyboard dimensions (WxDxH)	434 x 163 x 43 mm
