HIKVISION DS-1004KI User Manual

User Manual of the DS-1004K keyboard
21
Appendix 1
：
Specification
Model DS-1004KI
Joystick Four-Axis
Serial Port RS485 and RS232
Working Temperature
-10℃- +55℃
Working Humidity 10%-90%
Power Supply 12VDC
Power Consumption ≤10W
Dimension
(W×D×H)
434×163×43mm
Weight ≤1.25Kg

HIKVISION DS-1004KI Specifications

General

Numeric keypad	Yes
Keyboard layout	-
Pointing device	Trackball
Device interface	RS-485
Connectivity technology	Wired
Wrist rest	No
Product color	Black
Keyboard style	Straight
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Control panel
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	163 mm
Width	434 mm
Height	43 mm
Keyboard weight	1250 g
Keyboard dimensions (WxDxH)	434 x 163 x 43 mm
