User Manual of the DS-1004K keyboard
4

MENU: Keyboard Configuration Mode. Turn the key to the MENU. Set the keyboard parameters, such as the keyboard
address, the RS-485 parameters and the RS-232 parameters.

OPERATE: Keyboard Operation Mode. Turn the key to OPERATE. Under this mode, the keyboard can control the DVR,
PTZ of the dome camera and the matrix.

PROGRAM: Keyboard Function Settings Mode. Turn the key to PROGRAM. Under this mode, the keyboard can set the
parameters for preset, pattern and patrol.
Protocols
There are 63 protocols of the PTZ control of dome camera, and the main protocols are HIKVISION, PELCO-P, PELCO-D,
SAMSUNG, YAAN-1, SONY, SIEMENS, DRAGON, NAIJIE, KALATEL, VICON and etc..
The control protocols for the analog matrix are ZT-1.0, ZT-2.0, EXTRON, and CREATOR.
Cascade Connection
DS-1004KI provides the cascade connection, and 16 auxiliary keyboards are connectable. The address of the auxiliary keyboard
ranges from 0 to 255.
Other Features

The keyboard can set different RS485 parameters such as the protocol and the Baudrate, which enables the flexible parallel
connection to different devices.

The convenient key locking function ensures the security of operation.

The keyboard integrates multiple control functions as the controlling of DVR, analog dome cameras and matrix. It can be
used in the complex surveillance system.
 LED panel display is provided.

HIKVISION DS-1004KI Specifications

General

Numeric keypad	Yes
Keyboard layout	-
Pointing device	Trackball
Device interface	RS-485
Connectivity technology	Wired
Wrist rest	No
Product color	Black
Keyboard style	Straight
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Control panel
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	163 mm
Width	434 mm
Height	43 mm
Keyboard weight	1250 g
Keyboard dimensions (WxDxH)	434 x 163 x 43 mm
