Chapter 1 Overview
1.1 Description
Integrated with the built-in pan/tilt unit, the high speed dome features highly sensitive response
and reliable performance. The speed dome can be adopted in various surveillance fields with its
full-integral functions and features, such as forest, railway, airport, harbor, oil field, plaza, park,
scenic spot, street, train station, stadium, etc.
1.2 Functions
OSD (On Screen Display)
The on-screen display is an image superimposed on a screen picture, used for displaying
information and menu.
Self-adaptive Protocol
The speed dome is compatible with PELCO-D, PELCO-P, PRIVATE-Code, VICON and KALATEL-32
protocol, etc., and is capable of being self-adaptive to these protocols without selecting protocol by
DIP switch settings.
Keyboard Control
The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR,
matrix, etc.
Limit Stops
The dome can be programmed to move within the limit stops (left/right, up/down) which are
configurable by the control keyboard, DVR or client application software.
Auto Scan
The dome provides 5 scan modes: pan scan, tilt scan, frame scan, random scan and panorama scan.
The scan speed can be set by OSD menu from level 1 to 40, with the corresponding speed ranging
from 1°/second to 40°/second.
Preset Freeze Frame
This feature freezes the scene on the monitor when going to a preset. This allows for smooth
transition from one preset scene to another and also guarantees that masked area will not be
revealed when going to a preset.
Presets
Each of the user-definable presets can be programmed to use pan, tilt, camera settings and other
settings. When preset is called, the dome will automatically move to the defined position. User is
allowed to add, modify, delete and call each preset.
Label Display
The on-screen label of the preset title, azimuth/elevation, zoom and other operations can be
programmed by menu and displayed on the monitor.
Auto Flip
