User Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
53
1) Configure the FTP settings and check checkbox in FTP
Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more
details to configure FTP parameters.
2) Check the Enable Timing Snapshot checkbox.
Upload event-triggered snapshots to FTP
Steps:
1) Configure the FTP settings and check checkbox in FTP
Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more
details to configure FTP parameters.
2) Check checkbox in Motion Detection Settings or Alarm Input
interface. Please refer to Step 3 Set the Alarm Actions Taken for Motion
Detection in Section 6.6.1, or Step 4 Configuring External Alarm Input in Section
6.6.4.
3) Check the Enable Event-triggered Snapshot checkbox.
Figure 5-37 Snapshot Settings
Chapter 6 Storage Settings
Before you start:
To configure record settings, please make sure that you have the network storage
device within the network or the SD card inserted in your camera.

Table of Contents

Other manuals for HIKVISION DS-2CD2112-I

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2CD2112-I and is the answer not in the manual?

HIKVISION DS-2CD2112-I Specifications

General IconGeneral
TypeIP security camera
PTZ control-
Placement supportedOutdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Form factorDome
Mounting typeCeiling
Product colorWhite
Protection featuresVandal proof
International Protection (IP) codeIP66
Total megapixels1.3 MP
Maximum resolution1280 x 960 pixels
Supported video modes720p
Video formats supportedH.264, M-JPEG
Supported graphics resolutions704 x 576, 1280 x 960, 1280 x 720 (HD 720), 640 x 480 (VGA)
Pan range0 - 355 °
Tilt angle range0 - 65 °
Camera shutter speed1/25 - 1/100000 s
Minimum illumination0.01 lx
Field of view (FOV) angle73.1 °
Sensor typeCMOS
Optical sensor size1/3 \
Optical zoom- x
Focus adjustment2.0
Fixed focal length12 mm
Password protection typeUser
LED typeIR
Night vision distance30 m
Wi-FiNo
Cabling technology10/100Base-T(X)
Supported network protocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Ethernet LAN (RJ-45) ports1
DC output voltage+12V
Power source typePoE
Power consumption (max)7 W
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95 %
Weight and Dimensions IconWeight and Dimensions
Height82 mm
Weight500 g
Diameter111 mm
