HIKVISION DS-2CD6362F-I User Manual

User Manual of Network Fisheye Camera
86
By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and
the Parity and Flow Control is None.
Note: The Baud Rate, PTZ Protocol and PTZ Address parameters should be
exactly the same as the PTZ camera parameters.
9.10 Fisheye Parameters
Purpose:
Steps:
1. Enter the Fisheye Parameters interface:
Configuration > Basic Configuration> System > Fisheye Parameters
Or Configuration > Advanced Configuration> System > Fisheye Parameters
Figure 9-18 Fisheye Parameters
2. Select the stream mode from the drop-down list.
4 types of stream modes are selectable:
 Mode 1: Fisheye + Panorama + 3 PTZ
5 channels of video stream are available: 1 for Fisheye View, 1 for Panorama
View and 3 for PTZ View.
If Mode 1 is set for the stream mode, the following live view modes are
selectable on the live view interface: Fisheye View, Panorama View, Fisheye
+ 3 PTZ, Panorama + 3 PTZ, and Custom.
Note: The sub stream is not supported for the channels in Mode 1.
 Mode 2: Fisheye + 4 PTZ
5 channels of video stream are available: 1 for Fisheye View and 4 for PTZ
View.
If Mode 2 is set for the stream mode, the following live view modes are

HIKVISION DS-2CD6362F-I Specifications

General

Type	IP security camera
PTZ control	Yes
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Total megapixels	6 MP
Maximum resolution	3072 x 2048 pixels
Supported video modes	-
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	1024 x 768 (XGA), 2048 x 1536 (QXGA)
Camera shutter speed	1/25 - 1/100000 s
Minimum illumination	0.3 lx
Field of view (FOV) angle	360 °
Sensor type	CMOS
Optical sensor size	1/1.8 \
Optical zoom	- x
Focus adjustment	2.8
Fixed focal length	- mm
Password protection type	User
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	64 GB
LED type	IR
Night vision distance	15 m
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTC P, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Ethernet LAN (RJ-45) ports	1
Signal-to-Noise Ratio (SNR)	120 dB
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	11 W
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	152.8 mm
Width	164 mm
Height	43.8 mm
Weight	1400 g
