HIKVISION DS-6700HUHI-K Series

DS-6700HUHI-K Series Encoder User Manual
77
Figure 10. 3 Playback Toolbar
Table 10. 1 Description of Toolbar Icons
Icon
Operation
Icon
Operation
Select window-division mode
Reverse playback
/
Play/Pause
Stop playing
Slow forward
Fast forward
Play by single frame
Stop all channels from playing
Capture pictures in playback mode
Download video files
/
Start/Stop clipping video files
/
Audio on/off
Enable e-PTZ
Full screen
8. Drag the progress bar with the mouse to locate the exact playback point. Or input the time and click
to locate the playback point.
Figure 10. 4 Progress Bar
The color of the video on the progress bar stands for the different video types.
Figure 10. 5 Video Types
9. (Optional) Click to realize synchronous playback. Up to 4 cameras can be played back simultaneously. Click
to stop synchronous playback.
