User Manual of DS-7100HWI/HVI-SL/SH and DS-7200HI-SL Series DVR
110
3. Check checkbox to enable UPnP™.
4. Select the mapped type to Auto or Manual.
When you select Auto, the mapping ports can be automatically assigned by the router. When you select
Manual, you should continue Step5 to edit the mapping ports.
5. Click to open the External Port Settings dialog box. Configure the external port No. for server port,
HTTP port and RTSP port respectively.
You can use the default port No., or change it according to actual requirements.
External Port indicates the port No. for port mapping in the router.
Figure 9.14 External Port Settings Dialog Box
6. You can click Refresh to get the latest status of the port mapping.
Figure 9.15 UPnP™ Settings Finished
7. Click the Apply button to save the settings.
9.2.5 Configuring Remote Alarm Host
Purpose:
With a remote alarm host configured, the device will send the alarm event or exception message to the host
when an alarm is triggered. The remote alarm host must have the CMS (Client Management System) software
installed.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
