User Manual of Digital Video Recorder
53
6) Click OK to save setting and back to upper level menu.
Task 2: Draw the Schedule
Steps:
1) Click the icon on the right to select a record type, including Continuous, Motion and None.
To enable Motion triggered recording, you must configure the motion detection settings. For detailed
information, refer to Chapter 8.1.
2) Use the mouse to drag and draw time periods.
Up to 8 periods can be configured for each day.
Figure 5. 10 Draw the Schedule
3) You can repeat the above steps to set schedule for other channels. If the settings can also be used to
other channels, click Copy to enter the Copy Camera interface and then choose the channel to
which you want to copy.
Figure 5. 11 Copy Schedule to Other Channels
4) Click Apply in the Record Schedule interface to save the settings.
